Shinuan 100 Extrusion line


Last availability: Sept. 13, 2021

Listing description

Extrusion line for blowing 1 ply polymer films
2014 year
Manufacturer: Shinuan, China
Specifications
1. Film thickness: 0.01 - 0.1 mm; (Thickness: 5%)
2. Maximum film width: 1200 mm
3. The processed materials: PND, PVD, PVD + CaCO3 40%, PND + CaCO 40%;
4. Maximum performance: 100 kg / h;
5. Dimensions (L x B x H): 11000 x 2500 x 6000 mm;
6. Weight: 3t;
7. Main power: 60 kW;
Data sheet
1. Extruder
1.1 auger diameter: 50 mm
1.2 Ratio of length to diameter: 30: 1
1.3 Maximum screw rotation speed: 100 rpm
1.4 Type of screw: mixed type, with a barrier
1.5 control zones screw temperature: 4 zones
1.6 Heating Method: Double Stainless Heater
2. Extrusion head
2.1 Type of head: rotating head;
2.2 Material mandrel / matrix: alloy steel, forged and heat treated;
2.3 Diameter of the matrix: Ф250 mm (LDPE); F100 mm (PND);
2.4 The die gap: Ф250mm 1.3mm ; Ф 100mm 1.1 mm;
2.5 Surface of the head and chrome channels
2.6 Method of heating: dual layer heating element
3. A ring of an obduv (2 sets) (PVD + PND)
3.1 Type: Double Edge Blow Ring
3.2 Material: cast aluminum
3.3 Air blower power: 2.8 kW
4. Basket stabilization film bubble (1set.)
4.1 Type: circular structure
5. Folding frame and corner folding device
5.1 Material: steel support frame + special aluminum profile
6. Broaching device (1 set)
6.1 Power of the primary pulling engine: 1.5 kW
6.2 Feed Speed: 120 m / min.
6.3 Distance from floor surface: 6.0 m
6.4 Type of winder clamping device: pneumatic
6.5 Material winder: ethylene propylene rubber
7. Wrap (1 set)
7.1 Type of winder: automatic double winder back to back. Winder material: ethylene propylene rubber
7.2 Maximum winding width: 1200 mm
7.3 Maximum winding diameter: 800 mm
7.4 Maximum winding speed: 120 m / min.
7.5 Equipped with meter counter.
7.6 Device for removing static electricity from the winder: 2 pieces
8. Corona treatment device 1 set
9. Machine for processing recyclable film waste: 2 sets


Please note that this description may have been translated automatically.

Last availability: Sept. 13, 2021

Listing information

Manufacturer Shinuan
Model 100
Year 2014
Country Belarus Belarus
Condition Good
Main category Plastics
Subcategory Extrusion Line
ID P10913652
