Used 2006 COMEXI / METECOR MF6 Central drum (C.I.) flexo - 6 colors - 1220 mm

Listing description

Manufacturer: COMEXI / METECOR

Model: MF6

CENTRAL DRUM FLEXOGRAPHIC PRINTING MACHINE 6/120

MATERIALS TO PRINT:

Paper: from 25 to 140 gsm

Film (PE PP): from 30 to 120 my

TECHNICAL SPECIFICATION:

Material passage width: 1270 mm.

Max printing width: 1220 mm

Number of colors: 6

Unwinder reel max diameter: 800 mm

Rewinder reel max diameter: 800 mm

Gearless: No

MATERIALS TO PRINT:

- Paper: from 25 to 140 gsm

- Film (PE PP): from 30 to 120 my

Mechanical speed: 300 mt/min.

Printing speed: 250 mt/min. (depending on material)

Minimum printing repeat: 350 mm

Maximum printing repeat: 900 mm

Plate gear: 5 mm

Cliché thickness: 3 mm including the adhesive.

Mandrels inner diameter: 69 and 76 mm

Drying: Electric

Closed doctor blade chambers. Mechanical pressure regulation.

Electrical voltage: 380 V. 50 Hz.

Total installed power: 240 KW

Water pressure required: 2 bar

Compressed air: 7 bar

"Cantilever" system, designed to change sleeves on the machine :The machine is delivered with a set of sleeve holders, suitable to work with sleeves.

System to facilitate the ink tray changing and cleaning.

PRINTING UNIT PRE-POSITIONING: Motorized system that allows automatic forward and reverse

individual or simultaneous printing groups.

LONGITUDINAL REGISTRATION: By remote control, by electric motors.

LATERAL REGISTRATION: By remote control, by motors.

Adjustment: 15mm.

ACCESSORIES INCLUDED:

SLEEVES (Quantity x repeat): 7x 370 – 10x 400 – 7x 450 – 6x 500 – 7x 540 - 7x 600 – 8x 660

ANILOX (Quantity x Line screen): 2x 340/5 - 3x 280/5 - 2x 280/10 - 1x 160/9 - 3x 80/16 - 1x 80/18 - 1x GTT XL

PIGNONS (Quantity x repeat): 7x 355 - 7x 370 - 9x 400 - 6x 450 - 7x 500 - 5x 510 - 7x 540 - 10x 600 - 6x 660

OTHERS: (Quantity x item): 10X Racle – 5x reel shafts - 6z Inkwells – 12 ink tanks

This equipment is located in IT

Please note that this description may have been translated automatically.
