+GF+ Agie Charmilles CUT 30P Wire cutting edm machine Top seller

Price on request

Make an offer
manufacturer +GF+
model Agie Charmilles CUT 30P
year 2016
location Poland PL
category Edm - wire cutting machines
product id P250311437
language
bg Едм машина за рязане на тел +GF+ Agie Charmilles CUT 30P
cs Elektroerozivní drátová řezačka +GF+ Agie Charmilles CUT 30P
da +GF+ Agie Charmilles CUT 30P Trådskære edm maskine
de +GF+ Agie Charmilles CUT 30P Drahterodiermaschine
el Μηχάνημα κοπής συρμάτων edm +GF+ Agie Charmilles CUT 30P
en +GF+ Agie Charmilles CUT 30P Wire cutting edm machine
es Máquina de electroerosión por hilo +GF+ Agie Charmilles CUT 30P
fr Machine d'électro-érosion par fil +GF+ Agie Charmilles CUT 30P
hr EDM stroj za rezanje žice +GF+ Agie Charmilles CUT 30P
hu +GF+ Agie Charmilles CUT 30P Huzalvágó edm gép
it Elettroerosione a filo +GF+ Agie Charmilles CUT 30P
lt Vielos pjovimo edm mašina +GF+ Agie Charmilles CUT 30P
nl +GF+ Agie Charmilles CUT 30P Draadsnij-edm-machine
pl Wycinarka drutowa +GF+ Agie Charmilles CUT 30P
pt Máquina edm para corte de fio +GF+ Agie Charmilles CUT 30P
ro Mașină de tăiat cu sârmă EDM +GF+ Agie Charmilles CUT 30P
ru +GF+ Agie Charmilles CUT 30P Электроэрозионный вырезной станок
sr EDM mašina za sečenje žice +GF+ Agie Charmilles CUT 30P
sv +GF+ Agie Charmilles CUT 30P Trådskärning edm maskin
tr Tel erozyon makinesi +GF+ Agie Charmilles CUT 30P

Specifications

X Axis 23.62205 in
Y Axis 15.74803 in
Z Axis 13.77953 in
Max. workpiece length 40.55118 in
Max. workpiece width 31.49606 in
Max. workpiece height 13.77953 in
Max. workpiece weight 2204 lb
CNC Type
Automatic Wire Feeding Yes
-------------------
Weight 10336.76 lb
worked hours
hours under power
state as-is, where-is
At local norms ---------
status

Description

This 5-axis +GF+ Agie Charmilles CUT 30P wire EDM machine was manufactured in 2016. Ideal for precision cutting, it offers advanced control features and robust construction. Consider the opportunity to buy this +GF+ Agie Charmilles CUT 30P wire EDM machine. Contact us for more information.

Machine weight: 4690 kg
Number of axis: 5
X-Axis Movement: 600 mm
Y-Axis Movement: 400 mm
Z-Axis Movement: 350 mm
V-Axis Movement: ± 50 mm
U-Axis Movement: ± 50 mm
Workpiece weight: 1000 kg

Measurement device: glass scales (xy) / encoder (uvz)
Measurement resolution: 0. 1 µm
Max. Taper angle: ± 10° (57 mm height)
Max. Workpiece size: 1030 × 800 × 350 mm
Table size: 950 × 630 mm
Distance between table surface and floor: 1060 mm
Wire guide diameter: 0. 10 / 0. 15 / 0. 20 / 0. 25 / 0. 30 mm
Automatic wire threading diameter: 0. 15 / 0. 20 / 0. 25 / 0. 30 mm
Machine still under power

Please note that this description may have been translated automatically. Contact us for further information. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase


Client type Reseller
Active since 2019
Offers online 1165
Last activity May 16, 2025

Description

This 5-axis +GF+ Agie Charmilles CUT 30P wire EDM machine was manufactured in 2016. Ideal for precision cutting, it offers advanced control features and robust construction. Consider the opportunity to buy this +GF+ Agie Charmilles CUT 30P wire EDM machine. Contact us for more information.

Machine weight: 4690 kg
Number of axis: 5
X-Axis Movement: 600 mm
Y-Axis Movement: 400 mm
Z-Axis Movement: 350 mm
V-Axis Movement: ± 50 mm
U-Axis Movement: ± 50 mm
Workpiece weight: 1000 kg

Measurement device: glass scales (xy) / encoder (uvz)
Measurement resolution: 0. 1 µm
Max. Taper angle: ± 10° (57 mm height)
Max. Workpiece size: 1030 × 800 × 350 mm
Table size: 950 × 630 mm
Distance between table surface and floor: 1060 mm
Wire guide diameter: 0. 10 / 0. 15 / 0. 20 / 0. 25 / 0. 30 mm
Automatic wire threading diameter: 0. 15 / 0. 20 / 0. 25 / 0. 30 mm
Machine still under power

Please note that this description may have been translated automatically. Contact us for further information. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase
